| Specification | NDCF-920FSDC | NDCF-1224FSDC | NDCF-1628FSDC |
|---|---|---|---|
| Design speed (pcs/min) | 80 | 60 | 60 |
| Working speed (pcs/min) | 80 | 60 | 60 |
| Max feeding size (mm) | 900×2000 | 1200×2400 | 1600×2800 |
| Min feeding size (mm) | 280×650 | 350×680 | 500×680 |
| Max Depth of slotting (mm) | 230 | 300 | 300 |
| Registration precision (mm) | ≤±1.5 | ≤±1.5 | ≤±1.5 |
| Die cutting accuracy (mm) | ≤±0.5 | ≤±0.5 | ≤±0.5 |
| Printing plate thickness | 3.94 | 3.94 | 3.94 |
| Max.printing area (mm) | 2–12 | 2–12 | 2–12 |
| Min.slotting interval (mm) Normal | 150×150×150×150 | 150×150×150×150 | 150×150×150×150 |
| Min.slotting interval (mm) Reverse | 260×70×260×70 | 260×70×260×70 | 260×70×260×70 |
The chain feed flexo SDC is designed for standard B/C/E-flute single-wall and BC double-wall corrugated board. Suitable cardboard thickness ranges from 2 mm to 12 mm depending on the model. Please confirm your board specification when requesting a quote.
The machine supports 1 to 4 color printing configurations. Each color station is equipped with its own anilox roller and rubber/polymer printing plate. Color combinations can be selected according to your packaging design requirements.
Electric planetary phase adjustment on both the print and slotter units allows rapid, tool-free order changeovers. The optional plate hanging device further speeds up plate mounting. Typical order changes can be completed in under 10 minutes with a trained operator.
Print registration precision is ≤±1.5 mm and die cutting accuracy is ≤±0.5 mm under standard operating conditions. Chrome-plated rollers and hardened gear drives maintain these tolerances across sustained production runs.
Yes — installation, commissioning and operator training are included with every machine. Our engineers will remain on-site until the machine reaches target output, with ongoing after-sales support and spare parts supply available.
